40W Dimmable COB LED Down Light 3300LM CRI 80 60 degree IP20 TUV-CE Approved

  • 1
  • 2
  • 3

Place of Origin : China

Brand Name : MF

Certification : CE, RoHS

Model Number : MF-S170040

MOQ : 100PCS

Price : Negotiable

Packaging Details : 56×56×44cm/27pcs. G.W: 23KG

Delivery Time : Depends on orders

Payment Terms : T/T, Western Union, Paypal, L/C

Supply Ability : 10,000pcs/Month

Model No : MF-S170040

Input Voltage : AC 85 -277V, 110 / 220 VAC, 50 / 60Hz

Dimension(mm) : Dia 200*132mm

Cutting hole size(mm) : Dia170mm

Power : 40W

CCT : 2700K/3000K/4000K/5000K

Luminous Flux(lm) : 3100-3300lm

CRI : >80

Contact Now

40W Dimmable COB LED Down Light 3300LM CRI 80 60 degree IP20 TUV-CE Approved


Quick Detail:

  1. 40W COB LED Down Lights
  2. Input: AC 85V-277V, 110/120VAC ,50/60Hz
  3. Luminous Flux:3100-3300LM
  4. CRI: >80
  5. Beam Angle: 24°/60°
  6. Lifespan: ≧35000Hrs
  7. IP: 20
  8. Dimmable: Yes



Description:

MingFeng, as a prominent China LED down light company, devotes himself to providing high quality COB

quality COB LED down lights for the replacement of traditional down lights in residential, museum, office

and commercial applications.
MingFeng COB LED square down light is the most comprehensive architectural LED downlights in the market to replace CFL downlight, power from 10W to 40W, brightness from 830to 3500LM. Also CRI>80

is available, the whole series provide a collection of intelligent led lighting solutions, bringing a revolution for commercial ligting.


Specifications:

Model No

MF-S170040

Input voltage

85-277Vac , 110/220Vac, 50hz/60hz

Product Size

D200*132mm

Cut out Size

D170mm

Power(watt)

40W

Color temperature

2700K/3000K/4000K/5000K

LED Chip

CREE

PF

≥0.95

Luminous Flux (lm)

3100-3300LM

CRI(Ra)

>80

Lifespan

≥35000hrs

Beam Angle

60°

Material

Aluminum

Operating Temperature

-200C ~500C

Dimmable

Y

IP

20

Single Package 183×183X140mm/pcs
Carton Size 215×215X156mm/pcs,
66×66×34cm/18pcs. G.W: 22KG

Certificate

CE/RoHS

Warranty Period

3 years


Competitive Advantage:

  1. Die-casting heatsink, advanced cooling system.
  2. 24°/60° beam angle , soft light effect.
  3. High brightness CREE LED chip, CRI>80, Luminous Flux could from 830-3500LM.
  4. Luminous Efficiency >105lm/W.
  5. Smooth dimming or most dimmers.
  6. Isolation, IC constant current driver, and wide voltage 85-277VAC.




Dimension:

40W Dimmable COB LED Down Light 3300LM CRI 80 60 degree IP20 TUV-CE Approved


Packing:

40W Dimmable COB LED Down Light 3300LM CRI 80 60 degree IP20 TUV-CE Approved


Applications:

Widely used in automobile exhibition, clothing shop, furniture store, shoe stores, jewelry store, exhibition, art exhibition hall, the villa, and hotel, etc.

40W Dimmable COB LED Down Light 3300LM CRI 80 60 degree IP20 TUV-CE Approved
